LED DALI Driver Series
LED DALI Drivers are the most Intelligent LED Dimmable ones for LED Lighting lamps to get the very smart control system.Its work principle is that the dali signal wire be connected to Dali controller and then the dali controller sends the control signal data to dali driver and then control each led lamp's dimming according to our real lighting needs.We help our client to match the high quality LED DALI drivers to do their lighting projects with smart control. And they are widely used in the products of LED Panel Lights, LED track lights, LED ceiling lights, LED linear lights and LED Down Lights.
Features for LED Dali Dimming Driver:
Fuction for Dali dimming High Power Factor >0.95 AC Voltage: 100-277V AC High efficency: >87% ( 230VAC testing) Protection for short circuit, over voltage,over temperature Warranty for 3 years Output with more than 4 Channels. |  |
Dali LED Dimming Driver( Series I):
| Part No. | Power | Input(V) | Output(V) | Current | Efficency | PF | Flickering | Size(mm) |
| LS-21-D1-D15 | 48W | 100-277V | 27-42V | 1200mA | 86%-87% | >0.92 | D-No | 155*52*30 |
| LS-21-D1-D16 | 30W | 100-277V | 27-42V | 750mA | 85%-86% | >0.92 | D-No | 145*42*29 |
| LS-21-D1-D23 | 24W | 100-277V | 27-42V | 600mA | 86%-87% | >0.92 | S-Yes | 119*39*28 |
| LS-21-D1-D24 | 40W | 100-277V | 27-42V | 1000mA | 88%-89% | >0.92 | S-Yes | 145*44*29 |
| LS-21-D1-D25 | 56W | 100-277V | 27-42V | 1400mA | 88%-90% | >0.92 | S-Yes | 155*52*30 |
Parameters for Dali LED Dimming Drivers:
Surge Current(Max.): start in cooling,30A/230V
Overvoltage Protection: over the rated output Voltage:110%-130%
Overcurrent Protection: over constant current 95%-108%, recover when malfunction removes
Over Temperature Protection: enter into protection situation when themperature overs 90℃ +/-10℃(RTH2)
Start Time:230VAC，500ms
Withstand Voltage:3.75KVAC
Working Temperature:-20℃~+50℃
Safe Standards:UL8750，EN61347-1，EN61347-2-13 independent
Dimming Models: Sink & Source
EMC: Comploance to EN55015,EN61000-3-2 CLass C, EN61000-3-3,EN61000-4-2,3,4,5,6,8,11:EN61547,EN55024,industry level,criteria A
Application: LED Dali Dimming Drivers can use for lamps indoor: LED Down lights, LED Track lights, LED Panel Lights, LED Linear Lights and so on.
 |  |  |  |
DAli Dimming Driver Connect Drawing:
