LS-01-PL240120-MP Series are new design panels with muti-functions: lighting+decorative+lighting,Power:Optionals; Big Size Square Panel 2400x1200mm with different color and functions.high quality PMMA and 6063 Aluminum Profile with 20mm thickness, 2835 high brightness Osram/Philips/Epistar LED Chip. UGR<19 for lighting Optional; CRI>80/90Ra available; Customized Pictures can be made, which make your life colorful and wonderful. Application: all kinds of business shops for their goods advertisement; all kinds of office meeting rooms for their images; all kinds of company's front platform for company's cultures; all kinds of hotel halls for their hotel styles; all kinds of amusement places for their activities.
Features of Multi-function LED Panel Lights
Product name: Multi-function LED Panel Lights
Brand: Luxsky Lighting
Part number: LS-01-PL240120-MP Series
Size: 2400mm*1200*20mm
Input Voltage: AC100/200-277V, 50/60Hz
Function: lighting+decorative+lighting
Color: 3000K, 4000K,5000K,6000K; 3000-6000K optional
Power: 40W+60W+40W; 48W+60W+48W; 60W+70W+60W;
Functions: lighting +advertisement,( triac/1-10V/dali)dimming, sensor, CCT color adjust+dimming, Emergency
Materials: PMMA LGP+6063 aluminum profile+high quality LED+brand led drivers
IP rate: IP40; IK rate: IK08
Lumen efficiency: >120lm/W
CRI: >80Ra or >90Ra,
LED driver, no flickering
UGR<19 Optional
Pictures: customized
Power factor: >0.9
Installation: Suspended/ Surface Mounted
Certificates: CE& RoHs
Warranty: 5 years
Parameters of Multi-function LED Panel Lights
| Part No. | Power | Voltage | Functions | size(mm) | Flickering |
| LS-01-PL240120-MP-1 | 40W+60W+40W | AC100/200-240V(277V) | normal/non-dim | 2400mm*1200*20mm | non-flickering |
| LS-01-PL240120-MP-2 | 48W+70W+48W | AC100/200-240V(277V) | normal/non-dim | 2400mm*1200*20mm | non-flickering |
| LS-01-PL240120-MP-3 | 60W+70W+60W | AC100/200-240V(277V) | normal/non-dim | 2400mm*1200*20mm | non-flickering |
| LS-01-PL240120-MP-4 | 48W+60W+48W | AC100/200-240V(277V) | Triac dimming | 2400mm*1200*20mm | non-flickering |
| LS-01-PL240120-MP-5 | 48W+60W+48W | AC100/200-240V(277V) | 1-10V dimming | 2400mm*1200*20mm | non-flickering |
| LS-01-PL240120-MP-6 | 48W+60W+48W | AC100/200-240V(277V) | Dali dimming | 2400mm*1200*20mm | non-flickering |
| LS-01-PL240120-MP-7 | 40W+60W+40W | AC100/200-240V(277V) | CCT dimming(3000-6000K) | 2400mm*1200*20mm | non-flickering |
| LS-01-PL240120-MP-8 | 48W+60W+48W | AC100/200-240V(277V) | Microwave Sensor | 2400mm*1200*20mm | non-flickering |
| LS-01-PL240120-MP-9 | 48W+60W+48W | AC100/200-240V(277V) | Emergency(10W, 1.5H) | 2400mm*1200*20mm | non-flickering |
Size drawings of Multi-function LED Panel Lights
Application of Multi-function LED Panel Lights
Business shops; office meeting rooms; company's front platform; hotel halls; amusement places, etc.
 |  |  |
Packge of Multi-function LED Panel Lights
| Part No. | Carton size(mm) | Qty(pcs) | Net weight | Gross weight |
| LS-01-PL240120-MP | 2500*1300*120mm | 1pc | 28kg | 32.5kg |
