120W UFO LED Highbay Lights
Luxsky Lighting UFO series LS-03-HB-UFO-120W, LED Power 120W, AC85-277V Input,Lumileds SMD, meanwell UL driver, which is our new design and hotsales product, and can replaces the traditional LED highbay lights' large shape and save the space of package and installation becomes more easily and more convenient for shipment.What's more, it helps our clients to save much more profile in shipment; It is widely used in the high places, such as basketball halls, stadium, bus/train/airplane stations; big warehouse, factories workshork and warehouse, seaship warehouse and so on.
 |
 |
 |
v120W LED UFO Highbay Light Application:
|
LS-03-HB-UFO-120W high quality LED highbay lights are used in the places: Basketball hall, stadium, bus/train/airplane stations; big warehouse, factories workshork and warehouse. |
Big Factory Workshop |
 |
 |
v120W LED UFO Highbay's Specification:
|
Products Brand: Luxsky Lighting Product Name : 120W UFO LED Highbay light Color Temperature: 4000-4500K/5000-5500K/6000-6500K Light Power : 120W Color Rendering Index: >80Ra InputVoltage : 85-277V AC, 50Hz/60Hz Working voltage : DC30-40V Quantity of LEDs: 168pcs LED Brand: Lumileds SMD Lighting Efficency: 120-150lm/W LED luminous : >19500lms Light's Efficiency: >91% Illumiance Uniformity: >0.85 Power Factor: >0.95 THD : <20% UL Driver: Meanwell/Lumileds/Huatian
|
LED lifetime: 50,000 hours LED UFO Shell: Aluminum Fin Radiatior 6063 Reflector Beamangle: 90° or 120° Installation: hook/suspended/ceiling mounted LED working Temperature: -20°C to +60°C Storage Temperature:-25°C to +65°C Materials: LED+PCB+Driver+heatsink 6063 IP Rate: IP65 IK rate: IK08 Certificate: CE , RoHs, FCC, SAA Dimmable: 0-10V dimming; Dali Dimming Net weight:4.66kg warranty: 3years/5 years
|
v120W UFO LED Highbay Size and Reflector Size:
 |
|
| unit:mm Beamangle: 90° or 120° |
vLight Distribution Curve and Llluminance of 120W UFO Highbay:
 |
|
vInstallations of UFO 120W highbay Lights:
|
Installations of 120W UFO Highbays:
uHook Mounting uHanging Chain Mounting uCeiling Mounting
|
uHook Mounting Installation of 120W
lDrill corresponding size holes in the ceiling. Put the hook into the holes. lMaking the full fixture 's ring hang on the hook. Keeping it stable. l Notes distinguish the L / N / GND line.
|
|
uHanging Chain Installation of 120W
lDrill corresponding size holes in the ceiling, Put the Expansion bolts into holes. Fixed the hook on the ceiling with nut lAs Photo 2 showing , Using the chain's buckle button up the fixture's ring. lAs photo 3 showing , Hanging the chain's another-side ring on the hook with carefully l Notes distinguish the L / N / GND line. |
uCeiling Installation of 120W
lDrill corresponding size holes in the ceiling, Put the Expansion bolts into holes. Fixed the hook on the ceiling with nut. lLocking up the fixture's bracket and Wall-mounting bracket with screw. Which in a reasonable beam angle. lNotes distinguish the L / N / GND line
|
vPackage for UFO LED 120W Higbay Lights
(Note: Portable packaging, easy to carry)
|
Package size: 32cm*32cm*23cm G.W.:5.3kg; Volum weight: 4.98kg
|
|
Storage Environment: Ambient Operating Temperature range:-20 ℃ --- + 45 ℃ Environment Storage Temperature range:-25 ℃ --- + 65 ℃ Environment Ratings: dry and ventilated moisture-free environment |
vProduction & Old-Aging Test of UFO 120W Lights:
 |
 |
